2N2222A NPN General Purpose Transistor (TO-92) - 5 Pack
R60.00
Save 27% on bundle
R82.60 if bought individually
Buy and save
Buy and earn R0.34 Loyalty for your next purchase
Loyalty is a discount program that lets you buy products and earn points to redeem on your next purchase. Your Loyalty balance is updated when you pay online or in-store. The Loyalty amount shown on this page can be recalculated at the checkout.
In stock
1
2N2222A NPN General Purpose Transistor (TO-92) - 5 Pack
Product Details
A convenient 5-pack of the 2N2222A NPN general-purpose transistor in the classic TO-92 package — one of the most widely used switching and amplification transistors in electronics. Ideal for hobby projects, prototyping and repairs where you want a few spares on hand.
| Spec | – Value |
| Pack Quantity | – 5 transistors |
| Type | – NPN bipolar junction transistor (BJT) |
| Collector-Emitter Voltage (Vceo) | – 40 V |
| Collector Current (Ic) | – 800 mA (max) |
| Transition Frequency (fT) | – ~300 MHz |
| Power Dissipation (Ptot) | – 500 mW |
| hFE (DC current gain) | – 100–300 typical |
| Package | – TO-92 (3-pin) |
Handy Tips
- Check the pinout – On the TO-92, with the flat face toward you and legs down, the pins are commonly E-B-C, but always confirm against the datasheet as some variants differ.
- Switching workhorse – The 2N2222A switches loads up to ~800mA, making it great for driving small relays, LEDs and buzzers from a microcontroller pin.
- Add a base resistor – Always place a resistor (typically 1k–10k) between your control signal and the base to limit current and protect both the transistor and your driving pin.
- Amplification too – With its ~300MHz transition frequency it works well in small-signal audio and RF amplifier stages, not just switching.
- Flyback diode for coils – When switching relays or motors, fit a flyback diode across the coil to clamp back-EMF and protect the transistor.
- Know the PNP partner – The 2N2907 is the complementary PNP type; handy when building push-pull or H-bridge style circuits.
- Heat is rarely an issue – At 500mW dissipation it runs cool in most hobby uses, but keep within ratings when switching larger continuous loads.
