eSun eLastic Filament 1.75mm - Black (TPE-83A) - 1kg

eSun eLastic TPE‑83A Filament – Technical Specifications

• Plastic Type: Thermoplastic Elastomer (TPE‑83A)

• Plastic Diameter: 1.75mm

• Density (g/cm³): 1.14

• Distortion Temp (°C, 0.45MPa): 60

• Melt Flow Index (g/10min): 10 (190℃/2.16kg)

• Tensile Strength (MPa): 26

• Elongation at Break (%): 560

• Bending Strength (MPa): 6

• Bending Modulus (MPa): 8

• IZOD Impact Strength (kJ/m²): 20

• Total Weight: 1kg

Suggested Print Settings

• Nozzle Temperature (°C): 210 – 230

• Nozzle Material: Brass / Any

• Nozzle Size (mm): Standard 0.4mm

• Bed Temperature (°C): 30 – 60

• Printing Speed (mm/s): 20 – 30

• Part Cooling Fan: 50 – 100%

• Enclosure: Not necessary

• Adhesion: Masking paper, PVP solid glue, PEI

Key Features

• High elasticity and flexibility (Shore hardness 83A)

• Excellent elongation at break (up to 560%)

• Good impact resistance and toughness

• Soft rubber‑like feel, ideal for flexible parts

• Maintains shape while allowing stretch and compression

Typical Applications

• Wearable items (bands, straps, grips)

• Shock‑absorbing components

• Seals, gaskets, and vibration dampeners

• Flexible connectors and joints
