Inline Fuse Holder with ATC/ATO Blade Fuse Set (10A–40A) for 12V Systems
Share
R47.83
Buy and save
Buy and earn R0.27 Loyalty for your next purchase
Loyalty is a discount program that lets you buy products and earn points to redeem on your next purchase. Your Loyalty balance is updated when you pay online or in-store. The Loyalty amount shown on this page can be recalculated at the checkout.
In stock
1
Inline Fuse Holder with ATC/ATO Blade Fuse Set (10A–40A) for 12V Systems
Share
Product Details
| Spec | – Value |
|---|---|
| Fuse Type | – ATC/ATO Standard Blade Fuse |
| Included Fuse Ratings | – 10A, 15A, 20A, 25A, 30A, 40A |
| System Voltage | – 12V DC |
| Holder Wire Gauge | – Typically 14AWG (check product) |
| Connection Type | – Inline (series with load wire) |
| Waterproofing | – Cover/cap included (splash resistant) |
| Suitable For | – Cars, trucks, bakkies, boats, caravans, solar systems |
| Fuse Standard | – ATC (non-time delay) / ATO (open element) |
Handy Tips
- Always fuse at the source — Mount the inline fuse holder as close to the positive battery terminal or power source as possible (within 300mm ideally). This protects the entire length of wire from a short circuit, not just the load end.
- Match the fuse to the wire, not just the load — The fuse rating must not exceed what your wire gauge can safely carry. 14AWG wire is rated for approximately 15A continuous — using a 40A fuse on thin wire defeats the purpose of protection entirely.
- ATC vs ATO difference — Both ATC and ATO blade fuses are physically interchangeable in this holder. ATC fuses have a closed body for better vibration resistance, making them preferable in vehicles. ATO fuses have an open body allowing visual inspection of the element without removal.
- 12V DC only — This holder is rated for 12V DC automotive systems. Do not use on 240V AC mains circuits — blade fuses are not rated for mains voltage and present a serious shock and fire hazard if misapplied.
- Use for solar and caravan systems — Inline fuse holders are ideal for 12V solar setups, adding protection between your charge controller, battery, and DC loads such as lights, pumps, and inverters.
- Check the cap regularly — The protective cap keeps moisture and corrosion off the fuse contacts. In marine or outdoor environments inspect the cap and contacts every few months and apply a light coat of dielectric grease to prevent oxidation.
- Upgrade the wire if going above 20A — For the 25A, 30A, and 40A fuses to be meaningful, ensure your wiring is upgraded accordingly. 40A loads require at least 8AWG wire to avoid voltage drop and heat buildup over any meaningful cable run length.
